Dualsky 30A Brushless ESC

If you need a high-quality ESC, Dualsky's XC3012BA is hard to beat and is ideal for your 1 metre class aerobatic RC models.



Features

  • Comes with the latest software and hardware
  • Compatible with motor types up to 210,000rpm (2 poles motors)
  • Low resistance
  • Quality MosFETs included for high current usage
  • Compatible with Dualsky's Governor Mode (DGM)
  • Modifiable cut-off for motor stop or power reduction
  • Dualsky's Linear Brake Mode allows you to adjust the brake strength
  • Cut-off setting available for instances of low voltage
  • Overheating protection
  • Automatic cut-off in the event of a signal loss
  • Numerous start-up modes for fixed wing and helicopter setups
  • Throttle control throughout the range is smooth and reliable



Product Specifications

  • Dimensions (L x W x D): 47 x 26 x 7mm
  • Weight (g): 22
  • Number of Cells: NiXX 6-4, 7.2-14.4V/ LiPo 2-4, 7.4-14.8V
  • Resistance (Ri)(Ohm): 0.0059
  • Max Cont. Current (A): 30
  • Max Cont. Output (W): 420
  • Max Burst Current (A): 40
  • Max Burst Output (W): 544
  • BEC/ Dissipative Power: 5V/2A (2W Linear)
  • Programmable: Throttle + ProgCARD + USB LINK
  • Input Wires: 100mm, 16AWG, DC3
  • Output Wires: 65mm, 16AWG, DB3/DB2
  • Signal Wire: 180mm JR
  • Description: Mini, High Amp
  • Application: Small Models, 1m Class Aerobatic
