FMS EDF Jet 90mm Super Scorpion V2 PNP 6S Version

The all-new FMS 90mm EDF Super Scorpion V2 is here. Designed to elevate your flight experience with its upgraded inrunner motor and unique 12-blade fan. You'll feel the power and hear the difference! Choose between striking orange or camouflage paint schemes, both optimized for increased visibility and realism in flight. Available in 6S and 8S versions, this advanced sport jet delivers on every front; speed, stability, and maneuverability. Ready to master the skies? The Super Scorpion V2 has arrived!

Features

• Improved CNC-machined trailing link struts ensure smooth suspension and reduce impact force during takeoff, landing, and taxiing.
• Available in 6S (3670-KV1950 inrunner motor).
• Two paint scheme options: orange and camouflage.
• Electric retracts with locked-rotor mode and over-current protection.
• Multi-plug connectors for added durability, reliability, and ease of assembly.
• Preinstalled ball link connector enhances throw and precision.
• Screw-together assembly for easy setup.
• High-quality wear-resistant tires improve longevity.
• Buckle-design latch prevents unexpected canopy release in flight.
• Flap functionality aids in smoother takeoffs and landings.
• Environmentally friendly water-based paint offers better color and adhesion.
• Constructed with high-quality EPO foam for durability and lightweight performance.

What's In the Box

• 90mm Super Scorpion V2 EDF PNP.
• 120A ESC with reverse thrust function (installed).
• 6S (3670-KV1950 inrunner motor).
• 90mm 12-blade ducted fan (installed).
• 9 high-precision all-metal digital servos (installed).
• Product manual.

What You Need (Not Included)

• 6-channel transmitter and receiver.
• 6S (22.2V 5000mAh-6000mAh 45C with EC5 connector) or 8S (29.6V 5000mAh-5500mAh 45C with EC5 connector).
• LiPo battery charger.

Notes to Buyers

• RTF (Ready to Fly): Includes everything required to fly, such as a transmitter, receiver, battery, charger, and pre-installed electronics.
• PNP (Plug-and-Play): Includes ESC, motor, and pre-installed servos but excludes transmitter, receiver, battery, and charger.
• Heat Sensitivity: EPO foam and cockpits can bubble or deform in high heat. Avoid leaving them in direct sunlight when not in use.
• Reflex V3: Not included and must be purchased separately.
• Receiver Requirements: A 6-channel receiver is needed for Ailerons, Elevator, Throttle, Rudder, Landing Gear, and Flaps. Upgrade to 7 or more channels for advanced features such as thrust reverse and Reflex control.

Specifications: 6S vs. 8S Models

Dimensions:

• Wingspan: 1140mm / 44.9 in (both models).
• Overall Length: 1320mm / 52 in (both models).

Weight:

• 6S Model: Around 3500g.
• 8S Model: Around 3950g.

Power System:

• Engine: 3670-KV1950 (6S), 4075-KV1500 (8S).
• ESC: 120A (both models).

Servos:

• 13g Servos: 5 pcs (both models).
• 23g Servos: 4 pcs (both models).

Radio and Control:

• Radio: 6-channel (both models).
• CG (Center of Gravity): 150-160mm (both models).

Propulsion:

• Prop Size: 90mm 12-blade ducted fan (both models).
• Recommended Battery:
  • 6S Model: 22.2V 5000mAh-6000mAh 45C with EC5 connector.
  • 8S Model: 29.6V 5000mAh-5500mAh 45C with EC5 connector.

Control Features:

• Aileron: Yes (both models).
• Rudder: Yes (both models).
• Flaps: Yes (both models).
• Retracts: Yes (both models).

Performance:

• Approximate Flying Duration: 3 minutes (both models).

User Recommendations:

• Minimum Age: 14+ (both models).
• Experience Level: Intermediate (both models).
• Assembly Time: 10 minutes (both models).

Aerodynamics:

• Wing Load:
  • 6S Model: 119 g/dm_ (0.23 oz/in_).
  • 8S Model: 134.3 g/dm_ (0.26 oz/in_).
• Wing Area: 29.4 dm_ (455.5 sq.in) (both models).
