Hobbywing Skywalker 120A 8S V2

Type

• Brushed/Brushless: Brushless (BL)
• High Voltage/Regular: Regular

Product Specifications

• Continuous Current: 120A
• Peak Current: 150A
• Product Name: Skywalker 120A V2
• Product Number: 30205450
• Input Voltage: 3-8S LiPo
• BEC Output:
  • Switch Mode: 5V/6V/7.4V/8.4V
  • Continuous Current: 10A
  • Peak Current: 30A

Wires & Connectors

• Input Wires:
  • Red: 10AWG - 150mm x1
  • Black: 10AWG - 150mm x1
• Output Wires:
  • Black: 12AWG - 100mm x3
• Input Connectors: None
• Output Connectors: 4.0mm Gold Connectors (Female)

ESC Programming

• Transmitter: Not Supported
• LED Program Card: Not Supported
• LED Program Box: Supported
• LCD Program Box: Not Supported
• WiFi Module: Not Supported
• OTA Programmer: Not Supported
• Program Port: Supported

Firmware

• Firmware Upgrade: Not Supported

Size & Weight

• Size: 83 x 35 x 22mm
• Weight: 117g
