Quicrun 2030SL 5000KV Black G2 1/18 Brushless Motor

From Hobbywing the QuicRun 2030 G2 brushless motor. Suitable for all types of 1:18 scale vehicles.

Increased Efficiency

The maximum efficiency is increased by over 6%

Reduced Temperature

Under equivalent load conditions, the maximum temperature can be reduced by approximately 20℃
Compared to EzRun 2030 motor

Supports higher speed limit

The motor adopts an integrated magnetic ring structure to strengthen the rotor. It is able to support a higher speed limit of up to 65000RPM. It is increased by 4% when compared to EzRun 2030.

Excellent protection

The outlet of the motor is sealed with a silicone rubber sleeve to operate in harsh conditions such as dust, sand and gravel.
Note: It is recommended to block the unused mounting holes of the engine front end cover with screws.

Upgraded materials increased durability

• 0.2mm thick silicone steel sheet.
• High-strength explosion-proof rotor.
• High-temperature resistant enameled wire.
• High-precision bearings.

Plug-and-play

Wire outputThe motor output wires are soldered with 24k gold-plated 3.5mm plugs. The plug-and-play connectivity makes it easy to use and improves the quality of life.

Wide applicability

It is widely applicable with three KV values ​​to choose from. It is suitable for all types of 1:18 scale vehicles ranging from on-road to off-road vehicles, short course trucks, trucks, and monster trucks.

Features

• Improved Efficiency, Lower Temperature:
  Compared to the EzRun 2030 motor, our motor achieves over 6% increased maximum efficiency and can reduce maximum temperature by approximately 20% under equivalent load conditions.
• Higher Speed ​​Limit Support:
  With an integrated magnetic ring structure strengthening the rotor, our motor supports a speed limit up to 65000RPM, a 4% increase over the EzRun 2030.
• Higher Speed ​​Limit Support:
  With an integrated magnetic ring structure strengthening the rotor, our motor supports a speed limit up to 65000RPM, a 4% increase over the EzRun 2030
• Upgraded Durability:
  We've selected premium materials including 0.2mm thick silicon steel sheets, high-strength explosion-proof rotors, high-temperature resistant enameled wire, and high-precision bearings to ensure long-lasting performance.
• Gold-Plated Plug-and-Play Connectivity:
  Motor output wires feature 24k gold-plated 3.5mm plugs for easy, high-quality connectivity, enhancing user experience.
• Versatile Application:
  With three KV values ​​to choose from, our motor suits various 1/8th scale vehicles including on-road, off-road, short course trucks, regular trucks, and monster trucks.

Product Specifications

• Scale : 1/18th
• Brushed/Brushless : Brushless (BL)
• Sensored/Sensorless : Sensorless (SL)
• Pole Count : 2

Relevant Parameters

• KV Rating : 5000KV
• LiPo Cells : 2-3S
• No-Load Current (A) : 1.05A

Size & Weight

• Outer Diameter (OD) : 30 mm
• Length : 31 mm
• Shaft Diameter : 2 mm
• Weight : 42g
• Bearing : D8×D3×T4

Connectors

• Type : 3.5mm (Male)

Applications

• Vehicle Type : 1/18th

Recommended ESC

• Model : QUICKRUN WP 16BL30
