Paladin PL18 18 Channel Mode 2 2.4GHz Radio System w/FTr10 Receiver





Effortless Model Configuration (up to 18 channels)

For the first time fixed-wing, glider, helicopter, FPV, multicopter and construction vehicles are all supported in one radio. Now with the ability to take full advantage of up to 18 channels!

Smash all boundaries and do things your way with the Paladin PL18.



User Interface



Product Specifications



  • Channels: 18
  • Model Type: fixed wing, helicopter, crossing machine, multi-axis, engineering vehicle
  • RF: 2.4G
  • RF Power: < 20 dBm
  • 2.4GHz Protocol: AFHDS3
  • Distance: >3KM
  • Channel Resolution: 4096
  • Battery : 1S (3.7V) * 4300mAh (built-in)
  • Charging Interface : Micro USB / wireless charging
  • Charging Time: 6h@5V/7h@2A (wireless charging)
  • Life time: > 8h
  • Low Voltage Warning: <3.7V
  • Antenna Type : Dual antennaDisplay: HVGA 3.5" TFT, 320*480
  • Language: Chinese and English
  • Simulator: USB Simulator
  • Data Interface: USB, Non-standard interface (USART), PHJACK (PPM)
  • Temperature Range: -10 ° C - + 60 ° C
  • Humidity Range: 20%-95%
  • Online Update: support
  • Transmitter Color: black
  • Dimensions (length x width x height): 214*86.5*192 mm
  • Body weight : 946g
  • Certification CE, FCC ID: N4ZFT1800, RCM
