Spektrum S6245 High Speed High Torque Digital Servo - SPMSS6245



Product Information

This is the S6245 Standard Digital High-Speed High Torque Waterproof Metal Gear Surface Servo from Spektrum.

The latest generation of Spektrum surface servos provides you with the performance you need for any 1/10th scale vehicle application. The S6245 takes the race winning S6240 servo and upgrades it with a sleek, all aluminum, black anodized finish. The low profile design allows for space saving installation, making it the perfect servo for 1/10 racing buggies and trucks, bashers looking to upgrade their RTR vehicle, or for crawlers that need that extra speed and torque to push through demanding terrain.



Features

  • Stylish stealth black and silver anodized aluminium case*
  • Aluminium case provides great heat dissipation
  • High Voltage HV compatible (7.4V/2S Max)*
  • Improved torque and speed*
  • Removable wire harness with different lengths available
  • Improved gear design for added durability*
  • 7075 Aluminum hard anodized output shaft/main gear with steel internal gears
  • Includes 2-inch extension for easy minimum wire installs
  • Robust aluminium mounting tabs
  • NMB dual main output shaft bearings
  • 23T output shaft
  • Waterproof
  • 1-Year Limited Warranty

*Compared to S6240 Racing Servo



Product Specifications

  • Size Category: Standard
  • Type: Digital
  • Application: Surface
  • Torque: 206 oz-in (14.8kg-cm) @ 6V, 266 oz-in (19.2 kg-cm) @ 7.4V
  • Speed: 0.08 sec/60 deg @ 6V, 0.06 sec/60 deg @ 7.4V
  • Length: 1.61 in (41mm)
  • Width: 0.82 in (20.8mm)
  • Height: 1.18 in (30mm)
  • Weight: 2.2oz (62.37g)
  • Bushing Or Bearing: Bearing
  • Bearing: Dual
  • Motor Type: Coreless
  • Connector Type: 2.0 in (51mm) wire length
  • Gear Type: Metal
  • Gear Material: Metal
  • Voltage: 6.00 - 7.4V (HV)
