Savox SC-1251MG Low Profile Digital "High Speed" Metal Gear Servo - SAV-SC1251MG

Product Information

Whoever said that size doesn't matter was right! When talking about the SC1251MG we think about the saying "It's not the size of the dog in the fight, it's the size of fight in the dog." Combining full metal gears and amazing speed, the low-profile dimensions of this servo makes it perfect for any vehicle that is cramped for space or those looking to save additional weight.

Features

• Super high 4096 resolution and metal gears.
• Super light-weight.
• Coreless Motor provides high speed, incredible efficiency, and low power consumption than comparable servos.
• The aluminum case design not only looks good but also helps operation to remain cool and smooth.
• Our servos are totally green – from materials to production, these servos are environmentally friendly.
• Ideal as a steering servo for 1/10 surface applications and in gliders and airplanes that have thin wing profiles.

Product Specifications

• Dimensions(mm): 40.8X20.2X25.4
• Weight(g): 44.5
• Speed(@4.8V sec/60): .10
• Torque(@4.8V oz-in): 97.2
• Speed(@6.0V sec/60): .09
• Torque(@6.0V oz-in): 125.0
• Gear: Metal Bearing: 2BB
• Case: Aluminum 25 Tooth Spline

SC1251MG Servo FAQ

Q: What is the SC1251MG servo used for?

A: The SC1251MG servo is versatile and can be used in various applications, including 1/10 surface vehicles, gliders, and airplanes with thin wing profiles. It's typically used for steering and other control functions.

Q: What are the key features of the SC1251MG servo?

• Super high 4096 resolution and metal gears for precision and durability.
• Lightweight design to save weight in your vehicle or aircraft.
• Coreless motor for high speed, efficiency, and low power consumption.
• Aluminum case for cooling and smooth operation.
• Environmentally friendly materials and production.

Q: How compact is this servo?

A: The SC1251MG servo has dimensions of 40.8mm x 20.2mm x 25.4mm, making it low-profile and suitable for applications with limited space.

Q: What is the weight of the SC1251MG servo?

A: The servo weighs 44.5 grams, making it lightweight and suitable for weight-sensitive applications.

Q: What is the speed and torque of this servo at 4.8V?

A: At 4.8V, the SC1251MG servo has a speed of 0.10 seconds per 60 degrees (sec/60) and a torque of 97.2 oz-in.

Q: What is the speed and torque of this servo at 6.0V?

A: At 6.0V, the SC1251MG servo has a speed of 0.09 seconds per 60 degrees (sec/60) and a torque of 125.0 oz-in.

Q: What type of gears does this servo have?

A: The SC1251MG servo features metal gears for increased durability and performance.

Q: What kind of bearings does this servo use?

A: This servo uses 2BB (2-ball bearings) for smooth and reliable operation.

Q: What material is the servo case made of?

A: The servo case is made of aluminum, which not only looks good but also helps dissipate heat for smoother operation.

Q: Is the SC1251MG servo compatible with 25-tooth spline connectors?

A: Yes, this servo is compatible with 25-tooth spline connectors, making it suitable for a wide range of applications.
