Savox SH-0257MG plus Digital Metal Gear "High Speed" Micro Servo - SAV-SH0257MG



Product Information

This is the Savox SH-0257MG Super Speed Metal Gear Micro Digital Servo.



Features

• Over-spec refined design out performs ordinary micro size servo.
• The metal case design looks awesome and allows for cooler and smoother operating temps.
• Metal gears form a solid framework for precise control and operation.
• Strict production and quality control of plastic components.
• Ideal for CCPM and Rudder on 450 class heli's and park flyer airplanes.



Product Specifications

• Dimensions(mm): 22.8X12.0X25.4
• Weight(g): 14.0
• Speed(@4.8V sec/60): .13
• Torque(@4.8V oz-in): 25.0
• Speed(@6.0V sec/60): .09
• Torque(@6.0V oz-in): 30.6
• Gear: Metal
• Bearing: 1BB
• Case: Aluminum
• 21 Tooth Spline
• Frequency: 200-250hz
• Pulse Width Frequency: 1520

What is the Savox SH-0257MG Super Speed Metal Gear Micro Digital Servo used for?

This servo is commonly used for CCPM (Cyclic/Collective Pitch Mixing) and Rudder applications on 450 class helicopters and park flyer airplanes.

What makes the design of the Savox SH-0257MG servo stand out?

The servo features an over-spec refined design that outperforms ordinary micro servos. It also has a metal case design for better cooling and smoother operation.

Can you provide the specific dimensions and weight of the Savox SH-0257MG servo?

The servo's dimensions are 22.8mm x 12.0mm x 25.4mm, and it weighs 14.0 grams.

What are the speed and torque specifications for this servo at different voltage levels?

At 4.8V, the speed is 0.13 seconds per 60 degrees of rotation, and the torque is 25.0 oz-in. At 6.0V, the speed is 0.09 seconds per 60 degrees of rotation, and the torque is 30.6 oz-in.

What type of gears does the Savox SH-0257MG servo use?

The servo features metal gears, providing a solid framework for precise control and operation.

Does this servo come with a bearing, and if so, how many?

Yes, it comes with one ball bearing (1BB).

What material is the servo's case made of?

The case of the servo is made of aluminum.

How many teeth does the servo's spline have?

The servo has a 21-tooth spline.

What is the frequency range of this servo, and what is the pulse width frequency?

The frequency range is 200-250Hz, and the pulse width frequency is 1520µs.

Is this servo suitable for other applications aside from helicopters and park flyer airplanes?

While it's primarily designed for CCPM and Rudder applications on 450 class helicopters and park flyer airplanes, it may also be suitable for other applications that require a servo with similar specifications and size.
